Door check conveyor
| Version | Closing force | Article-Nr. |
|---|---|---|
| Spring force adjustable. | 5-50 N | 99940239 |
| Surface nickel plated. | ||
| Door closer with operating arm. | ||
| Other finishes available. |
Aditech D4 door closer are a simple and cost-effective door closing device suitable for all kinds of doors.
Installation Instructions for ADITECH conveyor
- Release the door conveyor by turning the clamping ring with the annexed pin. Remove the locking pin. See fig. 4.
- Fix the door conveyor with woodscrews at the doorframe. See fig. 1 and 2.
- Fix the guide of the rod at the door.
- Tense the tension element with the pin and ensure it with the locking pin. By turning the clamping ring the closing force can be adjust. See fig. 4.
If the door should stay open, the rod can be turn down. The door conveyor is also available with fixed rod. The finish is available in nickel-plated, zinc-coated or varnished version
